Output
|
|
Output
|
V1
|
V2
|
V3
|
V4
|
V5
|
5VSB
|
|
Voltage
|
+5V
|
3.3V
|
+12V
|
-5V
|
-12V
|
Standby
|
|
Max. Load
|
25A
|
15A
|
10A
|
0.5A
|
0.5A
|
2A
|
|
Min. Load
|
3A
|
0A
|
1A
|
0A
|
0A
|
0A
|
|
Max. Power
|
150W
|
|
2.5w
|
6w
|
7.5w
|
|
|
234w
|
|
|
|
|
|
Load Reg. %
|
±5%
|
±5/-3%
|
±5%
|
±10%
|
±10%
|
±5%
|
|
Cross Reg. %
|
±5%
|
±5%
|
±5%
|
±10%
|
±10%
|
±5%
|
|
Line Reg. %
|
±1%
|
±1%
|
±1%
|
±1%
|
±1%
|
±1%
|
|
Ripple %
|
±1%
|
±1%
|
±1%
|
±2%
|
±2%
|
±1%
|
|
Noise %
|
±1%
|
±1%
|
±1%
|
±2%
|
±2%
|
±1%
|
|
Input
|
|
Input voltage
|
90 to 264 VAC
|
|
Input frequency
|
47 to 63Hz
|
|
Input current
|
8.0A/115Vac, 4.0A/230Vac
|
|
GENERAL
|
|
Hold-up time
|
20mx at 115Vac/60Hz, 20ms at 230Vac/50Hz.
|
|
Efficiency
|
68%/115V; 68%/230V(full load)
|
|
MTBF
|
100,000hours at full load at 25°C
|
|
ENVIRONMENTAL
|
|
Operating temperature
|
0°C to +50°C
|
|
Storage temperature
|
-20°C to +80°C
|
|
Relative humidity
|
5% to 95% non-condensing
|
|
